丹佛斯旗下 Aeroquip DataCryo EHW194 液冷软管
Aeroquip by Danfoss EHW194 — 专为散热冷却工况打造
液冷是一项创新技术，以水作为冷却介质，降低数据中心设备处理器温度。丹佛斯立足这项新兴技术，开发出 DataCryo EHW194 软管。
本软管满足 UL 94 V-0 阻燃等级，具备优异柔韧性与抗扭结性能，可在狭小空间灵活布管，简化安装与维护工作。产品提供多种规格与配色，可适配丹佛斯认证接头，助力客户轻松布局液冷新兴市场。
产品特点
- 符合 UL 94 V-0 阻燃等级
- 性能优于 ASTM E84 1 级 / A 级标准
- 外层阻燃护套
- 护套表面光滑，摩擦系数低
- 多种颜色可选
- 柔韧性佳，耐扭转变形、抗弯折扭结
适用领域 / 应用场景
- 数据中心
- 电子元器件冷却
- 加密货币矿机散热
- IT 设备热管理
供货模式
- 常备库存现货供应
丹佛斯旗下 Aeroquip DataCryo EHW194 液冷软管 | Aeroquip by Danfoss EHW194 — 专为散热冷却工况打造
Aeroquip by Danfoss EHW194 Engineered to keep you cool
Aeroquip by Danfoss DataCryo EHW194
Part Number |
Order Number |
|
Colour |
Hose I.D. (mm) |
Hose I.D. (in) |
| EHW194TW-04 |
12026510 |
Blue |
6.4 |
0.25 |
13 |
| 12055014 |
Red |
6.4 |
0.25 |
13 |
| 12013458 |
Black |
6.4 |
0.25 |
13 |
| EHW194TW-06 |
12026512 |
Blue |
9.5 |
0.37 |
16 |
| 12055016 |
Red |
9.5 |
0.37 |
16 |
| 12008699 |
Black |
9.5 |
0.37 |
16 |
| EHW194-08 |
EHW194-08BURL |
Blue |
12.7 |
0.5 |
22 |
| EHW194-08RDRL |
Red |
12.7 |
0.5 |
22 |
| EHW194-08BKRL |
Black |
12.7 |
0.5 |
22 |
| EHW194-10 |
EHW194-10BURL |
Blue |
15.9 |
0.63 |
25.2 |
| EHW194-10RDRL |
Red |
15.9 |
0.63 |
25.2 |
| EHW194-10BKRL |
Black |
15.9 |
0.63 |
25.2 |
| EHW194-12 |
EHW194-12BURL |
Blue |
19 |
0.75 |
29.7 |
| EHW194-12RDRL |
Red |
19 |
0.75 |
29.7 |
| EHW194-12BKRL |
Black |
19 |
0.75 |
29.7 |
| EHW194-16 |
EHW194-16BURL |
Blue * |
25.4 |
1 |
36.5 |
| EHW194-16RDRL |
Red * |
25.4 |
1 |
36.5 |
| EHW194-16BKRL |
Black * |
25.4 |
1 |
36.5 |
* Hose colour is black with layline colour as indicated
Construction
Tube Peroxide-cured, zinc free, synthetic EPDM rubber
Reinforcement 2-ply textile
Cover Fire retardant, Peroxide-cure Synthetic EPDM Rubber
Colors Black (BK), Blue (BU), Red (RD)
100% Sulfur free construction
Max/Min Intermittent Operating Temperature
-40℃ to +140℃ (-40°F to +284°F)
Certifications
UL 94 V-0
Exceeds ASTM E84 Class 1/A Requirements
Packaging
76.2m (250 ft.) Reel
Qualified connections
? Danfoss 1G crimp fittings
? Danfoss 100B socketless fittings
? Danfoss Hansen UQD
? Danfoss Hansen FD83
| Part Number |
Order Number |
Colour |
Hose I.D.
(mm) |
Hose I.D.
(in) |
Hose O.D.
(mm) |
Hose O.D.
(in) |
| EHW194-20 |
11354729 |
Blue* |
32 |
1.25 |
44 |
1.73 |
| 11354843 |
Red* |
32 |
44 |
1.73 |
10.5 |
| EHW194-24 |
11354800 |
Blue* |
38 |
1.5 |
50 |
1.97 |
| 11354845 |
Red* |
38 |
50 |
1.97 |
10.5 |
| EHW194-32 |
11354938 |
Blue* |
50.8 |
2 |
64 |
2.52 |
| 11354972 |
Red* |
50.8 |
64 |
2.52 |
10.5 |
Construction
Tube Peroxide-cured, zinc free, synthetic EPDM rubber
Reinforcement 2-ply textile;
1 helical wire
Cover Fire retardant, Peroxide-cure
Synthetic EPDM Rubber
Colors Blue, Red (Layline)
100% Sulfur free construction
Max/Min Intermittent Operating Temperature -40℃ to +140℃
(-40℉ to +284℉)
Certifications UL 94 V-0 rated
Packaging 61m (200ft.) coil
Qualified connections
1 Danfoss 1G crimp fittings
2 Danfoss Hansen FD83 hose barb couplings
3 Danfoss EHW194 hose barb fittings
